The ‘cheap’ Chinese diesel heaters ar very in style among the vacationing & RVing community. However, like most things found on eBay, there's no such factor as ‘after care’ or ‘tech support.’ You build the acquisition, then you’re left to your devices to put in the factor and kind out any problems which will arise with the unit on the manner.

But don't despair! There ar multiple Facebook teams dedicated to the cause, full of different data and a military of useful individuals if you discover yourself in an exceedingly pickle. I’ve conjointly place along this Chinese diesel heater issues post with the maximum amount data as I may gather. enclosed ar the Error Codes beside several troubleshooting solutions, which individuals have found to be helpful with their own diesel heaters.

But don't despair! There ar multiple Facebook teams dedicated to the cause, full of different data and a military of useful individuals if you discover yourself in an exceedingly pickle. I’ve conjointly place along this Chinese diesel heater issues post with the maximum amount data as I may gather. enclosed ar the Error Codes beside several troubleshooting solutions, which individuals have found to be helpful with their own diesel heaters.

[100% fixed*] fixed chinese diesel heater error codes (complete solution)?

Chinese Diesel Air Heater Error Code E01 & E02

#Failure Performance

✅Usually, the recent diesel air heater includes a higher chance of E01 and E02.

✅Chinese diesel air heater starts operating, and also the heater running program can do a full check of all functions of the heater.

When the program detects a fault within the flame detector, the heater can show a fault code directly.

#Cause of Issue

Flame detector failure

#Error Code E01 & E02 Troubleshooting

✅Please check the plug of the flame detector whether or not it's loose, and reconnect the plug properly.

✅Replace the flame detector

Diesel Air Heater Error Code E03

#Failure Performance

✅The diesel air heater can work for over ten minutes and hot air is generated from the heater.

✅Then it stops operating associate degreed an E03 fault seems.

✅There will be black smoke initiating of the pipe, results of incomplete burning fuel.

✅Usually, new diesel air heaters have a better chance of E03.

#Cause of Issue

Temperature detector exceeds alarm temperature

#Error Code E03 Troubleshooting

✅Distance from the diesel heater cooling air recess to the obstacle, to possess 10-15 cm (4 inches – six inches).

✅Please check whether or not there's a blockage within the hot air outlet.

✅Please check the combustion air recess to create certain there's no blockage.

Diesel Air Heater Error Code E04

#Failure Performance

There is white smoke initiating of the diesel air heater combustion pipe and also the heater stops operating.

#Cause of Issue

The temperature detector detects a coffee flame temperature once the heater is burning.

#Error Code E04 Troubleshooting

✅The E04 fault is sometimes gift in each new and recent heaters.

✅The new diesel heater has E04 fault, please check if there's enough fuel within the tank. Is there any air bubbles gift within the fuel line and is that the association of the fuel line reliable. If there ar air bubbles gift, please check that the fuel line is freed from air bubbles.

✅The recent diesel heater has E04 fault, the primary factor to think about is that the rubber hose is aging, the fuel line is aging, or the filter is clogged and also the silent fuel pump is clogged. Solve these issues, the diesel heater work fine.

Diesel Air Heater Error Code E07

#Failure Performance

✅After beginning the diesel heater, the runtime program can find the voltage of the heater.

✅When the voltage is checked to be too high, a fault code seems on the panel and also the heater stops operating.

#Cause of Issue

Power offer voltage is just too high.

#Error Code E07 Troubleshooting

✅The voltage of 12V diesel heater mustn't be on top of 15V.

✅The voltage of 24V diesel heater mustn't be on top of 30V.

Diesel Air Heater Error Code E08

#Failure Performance

 ✅After beginning the diesel heater, the runtime program can find the voltage of the heater.

✅When it checks that the battery offer voltage is just too low, a fault code seems on the panel and also the heater stops operating.

#Cause of Issue

Power offer voltage is just too low

#Error Code E08 Troubleshooting

✅12V heater, the voltage is under DC 10V

✅24V heater, the voltage is under DC 20V

✅You need to interchange the battery.

Diesel Heater Error Code E09 & E11

#Failure Performance

✅When the diesel heater starts operating, the management program can check the heater operation system.

✅When the glow plug failure is detected, a fault code seems on the panel and also the heater stops in operation.

#Cause of Issue

Diesel heaters glow plug failure

#Error Code E09 & E11 Troubleshooting

✅The recent diesel heaters can seem E09 fault and E11 fault.

✅With a diesel heater that has been operating properly for 2-3 years, you may got to replace the glow plugs and fuel screen.

✅Please make sure the ignition plug association is reliable and not loose.

✅If the glow plug association is reliable, the glow plug is also faulty and you wish to interchange the glow plug.

Diesel Heater Error Code E12 & E13

#Failure Performance

✅After beginning the diesel heater, the heater operation program can absolutely check the perform of the heater.

✅When a combustion blower motor fault is detected, the heater can show a fault code and clean up.

#Cause of Issue

Diesel heaters combustion blower motor failure

#Error Code E12 & E13 Troubleshooting

✅The new diesel heater heater includes a higher chance of E12 failure.

✅It is typically the vane of the combustion motor that hits the heater housing. the answer is to regulate the clearance between the vane and also the housing.

✅The recent diesel heaters have a better chance of E13 failure.

✅It is potential that the heater motor is out of whack. you wish to interchange the combustion motor assembly.

Diesel Heater Error Code E14 & E15

#Failure Performance

✅When the diesel heater starts operating, the runtime program performs an intensive scrutiny of the heater elements.

✅When a fuel pump failure is detected, the heater can clean up and a fault code can seem on the panel.

✅The red lightweight of the panel can flash.

#Cause of Issue

Metering pump failure

#Error Code E14 & E15 Troubleshooting

✅Please check the association of the metering pump. If the association is loose, please build a brand new association.

✅If the association is reliable, please replace the metering pump.

Diesel Heaters Error Code E16

#Failure Performance

If associate degree E16 fault happens, the diesel heaters won't activate.

#Cause of Issue

Incorrect wire association between the diesel heater main unit and also the panel.

#Error Code E16 Troubleshooting

✅E16 failures ar typically found on new heaters.

✅Please make sure the wire plug association is reliable.

✅Or place the incorrect wire association. Please build a similar wire color association consistent with the colour of the wires of the heater and also the panel.

Diesel Heaters Error Code E19

#Failure Performance

✅The diesel heater can restart once a couple of minutes of operation {and can|and can} clean up once more and a fault code will seem on the panel.

✅During this method, white smoke can start of the pipe.

#Cause of Issue

The diesel heater cannot begin with success

#Error Code E19 Troubleshooting

✅The E19 fault is found in each new and recent heaters.

✅E19 fault happens in new diesel heaters.

✅Please check the equipment for the presence of air and take away the surplus air. Check the fuel tank for lack of fuel.

✅E19 fault happens within the recent diesel heaters.

✅Please check the equipment for aging components, fuel pump failure or aging fuel delivery line.Aging glow plugs.

Summary of chinese diesel heater error codes

If Chinese diesel heater blowing cold air

If diesel heater unable to turn on

Chinese diesel heater setting

(All image credit myrigadventure.com)

Conclusion:-

Many camper van homeowners might imagine that low-cost chinese heaters, unreliable in quality, and dearer diesel heaters, out of budget.Maybe you may wish to shop for fuel heaters. However, fuel heaters use fuel, and your camper van will simply get diesel. However, it'll be comparatively troublesome to get fuel. Moreover, the heating power output of the diesel heater is on top of the fuel heater.

If you browse our article, you may be able to select the simplest diesel heater with the foremost cost-efficient worth.Thank you.
